Конструкції електричних машин постійного струму з безобмотковим ротором для високих і низьких швидкостей обертання
Вантажиться...
Дата
2020
Автори
Косенков, В.Д.
Івлєв, Д.А.
Kosenkov, V.D.
Ivlev, D.A.
Назва журналу
Номер ISSN
Назва тому
Видавець
Хмельницький національний університет
Анотація
Для будь-якої електричної машини основними є два показники: мінімум маси й максимум ККД. Для
високообертових і низькообертових машин постійного струму з безобмотковим ротором ці два показники
досягаються різними засобами. У першому випадку цільний статор із загальним ярмом і сегментований ротор. У
другому випадку – сегментований статор і цільний ротор. Завдяки такому підходу досягається значне
поліпшення ряду питомих показників і зниження витрат електричної енергії в статичних і динамічних режимах
роботи електропривода.
For any electric machine, the main two indicators are minimum mass and maximum efficiency. For high-speed and low-speed DC machines with the windless rotor, these two values are achieved in different ways. In the first case, a one-piece stator with a common yoke and a segmented winding-free rotor. In the second case, a segmented stator and a one-piece rotor. Thanks to this approach, a significant improvement in a number of specific indicators and a decrease in the consumption of electrical energy in static and dynamic modes of operation of the electric drive are achieved.
For any electric machine, the main two indicators are minimum mass and maximum efficiency. For high-speed and low-speed DC machines with the windless rotor, these two values are achieved in different ways. In the first case, a one-piece stator with a common yoke and a segmented winding-free rotor. In the second case, a segmented stator and a one-piece rotor. Thanks to this approach, a significant improvement in a number of specific indicators and a decrease in the consumption of electrical energy in static and dynamic modes of operation of the electric drive are achieved.
Опис
Ключові слова
ротор, статор, обмотка, магнітна система, втрати в сталі, rotor, stator, armature winding, magnetic system, iron losses
Бібліографічний опис
Косенков В. Д. Конструкції електричних машин постійного струму з безобмотковим ротором для високих і низьких швидкостей обертання / В. Д. Косенков, Д. А. Івлєв // Вісник Хмельницького національного університету. Технічні науки. – 2020. – № 5. – С. 218-221.
