Числові дослідження гідророзподільного пристрою плісирувальної машини за допомогою модуля floworks
Вантажиться...
Файли
Дата
2018
Автори
Коротич, О.О.
Неймак, В.С.
Пундик, С.І.
Майдан, П.С.
Korotych, O.O.
Neymak, V.S.
Pundyk, S.I.
Majdan, P.S.
Назва журналу
Номер ISSN
Назва тому
Видавець
Хмельницький національний університет
Анотація
На основі аналізу конструкції плісирувальної машини ножового-валкового типу, три виконавчих механізми
якої отримують рух від електропривода через ланцюги передаточних механізмів, авторами розроблено гідравлічну
систему розподілення руху на робочі механізми плісирувальної машини, що може виконувати, як розподільну, так і
керуючу функцію та може замінити керовані автоматичні пристрої. В цілому плісирувальна машина має спрощену
конструкцію і підвищену надійність. Проте на даний момент не існує можливості для підключення його в мережу
високого тиску, тому для перевірки працездатності запропонованого гідравлічного обладнання проведено цикл
експериментальних досліджень, застосувавши модуль FloWorks для системи параметричного моделювання
SolidWorks. Отримано результати розподілу рідини у розподільнику для окремих порожнин, що приводять у рух
робочі органи плісирувальної машини, зокрема механізму подачі складкоутворюючих елементів (ножів), механізму
захоплення матеріалу та механізму для подачі і термофіксації матеріалу.
Developed a new original hydraulic distributor design which provides the supply fluid according to a cycle diagram work on three major hydrocylinder for the working mechanisms of the machine for pleating. On the basis of the analysis of the structure of a knife-roller pleasing machine, the three actuators of which are driven by the electric drive through the chain of gear mechanisms, the authors developed a hydraulic system for distributing motion on the working mechanisms of the plasticizer. Hydraulic and hydro-kinematic schemes of the machine, working drawings of parts and assembly drawings of the hydraulic distributor are developed. The new original design of the hydraulic distributor ensures the supply of the working fluid in accordance with the cyclic diagram of the work on three hydraulic cylinders of the main working mechanisms of the plasticizer. The developed hydrodistributor can perform both distributive and control functions that can replace the controlled automatic devices. In general, the plasticizer has a simplified design and increased reliability. However, at the moment there is no possibility to connect it to a high-pressure network, therefore, for checking the efficiency of the proposed hydraulic equipment, a cycle of experimental studies was conducted using the FloWorks module for the SolidWorks parametric modelling system. The results of distribution of the liquid in the distributor for separate cavities, which result in the movement of the working bodies of the pleasing machine, in particular the mechanism of feeding the fold-forming elements (knives), the mechanism of material capture and the mechanism for feeding and thermofixing of the material, are obtained.
Developed a new original hydraulic distributor design which provides the supply fluid according to a cycle diagram work on three major hydrocylinder for the working mechanisms of the machine for pleating. On the basis of the analysis of the structure of a knife-roller pleasing machine, the three actuators of which are driven by the electric drive through the chain of gear mechanisms, the authors developed a hydraulic system for distributing motion on the working mechanisms of the plasticizer. Hydraulic and hydro-kinematic schemes of the machine, working drawings of parts and assembly drawings of the hydraulic distributor are developed. The new original design of the hydraulic distributor ensures the supply of the working fluid in accordance with the cyclic diagram of the work on three hydraulic cylinders of the main working mechanisms of the plasticizer. The developed hydrodistributor can perform both distributive and control functions that can replace the controlled automatic devices. In general, the plasticizer has a simplified design and increased reliability. However, at the moment there is no possibility to connect it to a high-pressure network, therefore, for checking the efficiency of the proposed hydraulic equipment, a cycle of experimental studies was conducted using the FloWorks module for the SolidWorks parametric modelling system. The results of distribution of the liquid in the distributor for separate cavities, which result in the movement of the working bodies of the pleasing machine, in particular the mechanism of feeding the fold-forming elements (knives), the mechanism of material capture and the mechanism for feeding and thermofixing of the material, are obtained.
Опис
Ключові слова
гідравлічний розподільник, циклічна діаграма роботи машини, гідропривід виконавчих механізмів, числові дослідження, the hydraulic distributor, cycle diagram work, hydro-drive executive mechanisms, numerical research
Бібліографічний опис
Числові дослідження гідророзподільного пристрою плісирувальної машини за допомогою модуля FloWorks [Текст] / О. О. Коротич, В. С. Неймак, С. І. Пундик, П. С. Майдан // Вісник Хмельницького національного університету. Технічні науки. – 2018. – № 5. – С. 199-201.
