Методи підвищення якості спектральних характеристик високошвидкісних обчислювальних синтезаторів частоти (DDS)
Вантажиться...
Файли
Дата
2013
Автори
Полікаровських, О.І.
Polikarovskykh, O.I.
Мішан, В.В.
Mishan, V.V.
Назва журналу
Номер ISSN
Назва тому
Видавець
Хмельницький національний університет
Анотація
Розглянуто методи підвищення якості спектральних характеристик синтезованих сигналів
обчислювальних синтезаторів частоти. Запропоновані структури синтезаторів із покращеними спектральними
характеристиками. Застосування запропонованих структур синтезаторів дозволить зменшити рівні поза
смугових випромінювань апаратури радіозв’язку, що використовує цифрові обчислювальні синтезатори.
Methods of improving the quality of the spectral characteristics of the synthesized signal DDS. The proposed structure DDS with improved spectral characteristics. Application of the proposed structures synthesizers will reduce the level of spurs outside the band radio equipment that uses DDS. The methods and means of reducing the lateral spectral components in the output spectrum of the classical computational synthesizer based on accumulative adder. We found that it is possible to build a synthesizer with high tactical and technical characteristics of the algorithm used by Wheatley. The possibilities of the application of new mathematical approaches for building adders without a problem propagation delay signal transfer from the category in the category codeword. Consider a Boolean algebra operations over a couple of numbers and the theory of Galois fields to improve performance synthesizer. The mathematical apparatus will build a digital computer synthesizer with lower levels of lateral components in the spectrum of the output signal, due to some complications of the internal structure of the synthesizer using two additional adders and pseudo-random number generator.
Methods of improving the quality of the spectral characteristics of the synthesized signal DDS. The proposed structure DDS with improved spectral characteristics. Application of the proposed structures synthesizers will reduce the level of spurs outside the band radio equipment that uses DDS. The methods and means of reducing the lateral spectral components in the output spectrum of the classical computational synthesizer based on accumulative adder. We found that it is possible to build a synthesizer with high tactical and technical characteristics of the algorithm used by Wheatley. The possibilities of the application of new mathematical approaches for building adders without a problem propagation delay signal transfer from the category in the category codeword. Consider a Boolean algebra operations over a couple of numbers and the theory of Galois fields to improve performance synthesizer. The mathematical apparatus will build a digital computer synthesizer with lower levels of lateral components in the spectrum of the output signal, due to some complications of the internal structure of the synthesizer using two additional adders and pseudo-random number generator.
Опис
Ключові слова
АЦП, ЦАП, обчислювальний синтезатор частоти, фазовий акумулятор, поле Галуа, алгебра логіки, ADC, DAC, Galois, direct frequency synthesizer (DDS)
Бібліографічний опис
Полікаровських, О. І. Методи підвищення якості спектральних характеристик високошвидкісних обчислювальних синтезаторів частоти (DDS) [Текст] / О. І. Полікаровських, В. В. Мішан // Вісник Хмельницького національного університету. Технічні науки. – 2013. – № 5. – С. 208-211.
