Дослідження впливу вібрацій на роботу функціональних плат PEA
Вантажиться...
Дата
2015
Автори
Ковтун, Л.О.
Ройзман, В.П.
Яновицький, О.К.
Kovtun, L.O.
Roizman, V.P.
Janovitskiy, O.K.
Назва журналу
Номер ISSN
Назва тому
Видавець
Хмельницький національний університет
Анотація
В роботі досліджувався вплив вібрацій на функціональні плати, визначено власні частоти коливань
розрахунковими та експериментальними методами для знаходження резонансів, щоб уникати роботу апаратури
у цих режимах.
Abstract – circuit boards, walls of structure, and some other structural elements of products of REA in operating conditions not only themselves may be influenced by vibration and shock loads, but also to transfer these loads are mounted on these blocks, and chips electric radioelements. If wages and other supporting elements experience resonant vibrations, these dynamic loads are increasing many times and can lead to breakdowns or failures due to REA deviation parameters are located on blocks and elements beyond the committed specifications. The work is dedicated to finding the frequencies of the calculated and experimental methods and the possible resonances to avoid malfunction of these regimes. Analysis of the research showed that the range of operating frequencies and circuit boards with complex shape fluctuations, indicating that the strain most boards and modules installed on them.
Abstract – circuit boards, walls of structure, and some other structural elements of products of REA in operating conditions not only themselves may be influenced by vibration and shock loads, but also to transfer these loads are mounted on these blocks, and chips electric radioelements. If wages and other supporting elements experience resonant vibrations, these dynamic loads are increasing many times and can lead to breakdowns or failures due to REA deviation parameters are located on blocks and elements beyond the committed specifications. The work is dedicated to finding the frequencies of the calculated and experimental methods and the possible resonances to avoid malfunction of these regimes. Analysis of the research showed that the range of operating frequencies and circuit boards with complex shape fluctuations, indicating that the strain most boards and modules installed on them.
Опис
Ключові слова
вібрація, функціональна плата, власна частота коливань, vibration, functional plata, the natural frequency of oscillation
Бібліографічний опис
Ковтун, Л.О. Дослідження впливу вібрацій на роботу функціональних плат PEA [Текст] / Л. О. Ковтун, В. П. Ройзман, О. К. Яновицький // Вісник Хмельницького національного університету. Технічні науки. – 2015. – № 1. – С. 64-71.
