Вимірювання просторового положення та орієнтація в просторі конструкцій кварцових резонаторів
Вантажиться...
Дата
2014
Автори
Стецюк, В.І.
Stetsyuk, V.I.
Назва журналу
Номер ISSN
Назва тому
Видавець
Хмельницький національний університет
Анотація
В роботі розглядається геометрія кристалів кварцу, основні типи зрізів та їх класифікація, а також
математичний апарат поворотів осей координат. Приведена методика вимірювання просторового положення
та орієнтації в просторі конструкцій кварцових резонаторів за допомогою розробленого приладу.
This paper considers the geometry of quartz crystals, the main types of cuts and their classification and mathematical tools rotation axes. Present methods of measuring the spatial position and orientation in space structures quartz resonators using the developed device. Developed and practically implemented by measuring the spatial position for research vibrofrequency characteristicspiezoresonance devices, which is based on a microcontroller and two triaxial accelerometer sensors. The device allows the positioning structures of quartz resonators, a series of measurements, as well as the automation of the calculation process using the PC.
This paper considers the geometry of quartz crystals, the main types of cuts and their classification and mathematical tools rotation axes. Present methods of measuring the spatial position and orientation in space structures quartz resonators using the developed device. Developed and practically implemented by measuring the spatial position for research vibrofrequency characteristicspiezoresonance devices, which is based on a microcontroller and two triaxial accelerometer sensors. The device allows the positioning structures of quartz resonators, a series of measurements, as well as the automation of the calculation process using the PC.
Опис
Ключові слова
кварцовий резонатор, п’єзоелемент, зріз, вимірювач, quartz resonators, piezoelement, cut, meter
Бібліографічний опис
Стецюк, В. І. Вимірювання просторового положення та орієнтація в просторі конструкцій кварцових резонаторів [Текст] / В. І. Стецюк // Вісник Хмельницького національного університету. Технічні науки. – 2014. – № 5. – С. 119-122.
