Визначення кінематичних параметрів деформування тонкостінних конусів
Вантажиться...
Дата
2016
Автори
Марченко, В.Л.
Цимбалюк, В.М.
Marchenko, V.L.
Tsymbaliuk, V.M.
Назва журналу
Номер ISSN
Назва тому
Видавець
Хмельницький національний університет
Анотація
Розглянуто процес штампування тонкостінних конусів. Характерною його ознакою є наявність високих
контактних тисків, які суттєво впливають на міцність інструмента та точність деталей. Найбільш доцільним
в цьому випадку є використання технології штампування з крученням. Відомі аналітичні рішення для визначення
контактних тисків, що можуть бути використані при розрахунках інструменту, досить складні і не дозволяють
в явному вигляді визначити необхідні параметри деформування. Це призводить до необхідності багаторазового
виконання обчислень. За результатами проведених досліджень отримали нові співвідношення, що дозволяють
врахувати вплив параметрів інструмента і режимів деформування на забезпечення заданого рівня напруженодеформованого
стану. Порівняння результатів обчислень показало їх задовільну точність.
The process of punching thin cones is considered. Its characteristic feature is the presence of high contact pressures that significantly affect the strength of instrument and precision of parts. The most appropriate in this case is the use of stamping with twisting technology. Known analytical solutions for the determination of contact pressures that can be used in the calculations of tool, very complex and do not allow explicitly make deformations settings. This causes to the necessity of multiple computing executions. The results of the research have new correlations which allow for the impact of instrument parameters and regimes of deformation to provide a given level of stressstrain state. Comparison of results of calculations revealed satisfactory accuracy.
The process of punching thin cones is considered. Its characteristic feature is the presence of high contact pressures that significantly affect the strength of instrument and precision of parts. The most appropriate in this case is the use of stamping with twisting technology. Known analytical solutions for the determination of contact pressures that can be used in the calculations of tool, very complex and do not allow explicitly make deformations settings. This causes to the necessity of multiple computing executions. The results of the research have new correlations which allow for the impact of instrument parameters and regimes of deformation to provide a given level of stressstrain state. Comparison of results of calculations revealed satisfactory accuracy.
Опис
Ключові слова
штампування з крученням, тонкостінні конуси, режими деформування, епюра контактних тисків, punching with torsion, thin walled cones, modes of deformation, ontact pressure diagrams
Бібліографічний опис
Марченко, В.Л. Визначення кінематичних параметрів деформування тонкостінних конусів [Текст] / В. Л. Марченко, В. М. Цимбалюк // Вісник Хмельницького національного університету. Технічні науки. – 2016. – № 6. – С. 22-26.
