Модель процесу визначення геометричних характеристик бульок на зображенні піни
Вантажиться...
Дата
2013
Автори
Кльоц, Ю.П.
Klots, Y.P.
Грищук, А.О.
Grischuk, A.O.
Назва журналу
Номер ISSN
Назва тому
Видавець
Хмельницький національний університет
Анотація
В статті представлено модель процесу визначення геометричних характеристик бульок на зображенні
піни, що дозволяє в режимі реального часу підрахувати кількість та визначити геометричні характеристики
бульок на зображенні піни, отриманої за допомогою webкамери,
змонтованої на мікроскопі. Модель представлена
у вигляді послідовності перетворень зображення піни, в результаті якого ідентифікуються бульки на зображенні
піни та визначаються їх діаметри. Перетворення передбачають виконання матричних операцій згладжування та
визначення границь об’єктів над матрицею зображення. Достовірність визначення кількості та діаметрів
бульок, оцінена за допомогою критерію χ2, складає 86,3%. Це дозволяє відмовитись від ручного визначення
геометричних характеристик піни і автоматизувати процес її аналізу.
This paper presents a process model for the geometric characteristics determining of the bubbles on the foam image, allowing realtime count and determine geometric characteristics of the foam bubbles on the image obtained using the webcamera mounted on the microscope. The model is represented as a sequence of transformations the image foam, in which bubbles are identified in the image foams and determined their diameters. Transformations perform matrix operations include smoothing and defining the boundaries of objects on the image matrix. The reliability of determining the number and diameters of bubbles, estimated by χ2 test is 86.3%. This allows you to give up manually determine the geometrical characteristics of the foam bubbles and automate the process of foam analysis.
This paper presents a process model for the geometric characteristics determining of the bubbles on the foam image, allowing realtime count and determine geometric characteristics of the foam bubbles on the image obtained using the webcamera mounted on the microscope. The model is represented as a sequence of transformations the image foam, in which bubbles are identified in the image foams and determined their diameters. Transformations perform matrix operations include smoothing and defining the boundaries of objects on the image matrix. The reliability of determining the number and diameters of bubbles, estimated by χ2 test is 86.3%. This allows you to give up manually determine the geometrical characteristics of the foam bubbles and automate the process of foam analysis.
Опис
Ключові слова
піна, булька, камера, модель процесу, мікроскоп, перетворення зображення, foam camera, bubble, camera, microscope, process model, image conversion
Бібліографічний опис
Кльоц, Ю. П. Модель процесу визначення геометричних характеристик бульок на зображенні піни [Текст] / Ю. П. Кльоц, А. О. Грищук // Вісник Хмельницького національного університету. Технічні науки. – 2013. – № 6. – С. 221-229.
