Особливості квазікогерентної обробки сигналів у засобах телекомунікацій з частотною маніпуляцією
Вантажиться...
Дата
2018-02-14
Автори
Бойко, Юлій Миколайович
Пятін, Ілля Станіславович
Boiko, J.M.
Pyatin, I.S.
Назва журналу
Номер ISSN
Назва тому
Видавець
Державний університет телекомунікацій, Київ
Анотація
Розглянуто принципи аналітичного опису формування сигналів частотної маніпуляції в
телекомунікаційних системах. Проведений аналіз впливу кінцевої розрядності обчислень на якість
обробки сигналу. Досліджено умови реалізації моделі перетворювача частоти з її пониженням при
дискретизації на основі каскадних фільтрів. Експериментально досліджено вимоги до вибору
параметрів децимації сигналів при їх обробленні в умовах шумів.
Опис
The paper represents the principles of analytical description the formation of signals frequency
manipulation in telecommunication systems. The peculiarities of quasi-coherent processing of signals of
frequency manipulation on the basis of digital frequency downstream transformation with subsequent filtration
and multiple decimation are described. The analysis of the influence of finite-dimensional calculations on the
quality of signal processing is carried out, which can be further used to select the internal computational
discharges of digital downconversions while preserving the given quality of signal processing and hardware
costs for its realization. The conditions of realization of the model of the frequency converter with the decrease
of the sampling rate on the basis of cascade filters are investigated. The requirements for the selection of
signal decimation parameters when eating in the noise conditions are experimentally investigated. The
conditions for implementation of the model of the frequency converter with lower frequency sampling based
on cascaded filters CIC (Cascaded integrator-comb) filters and formation of characteristics of cascade on the
basis of programmable filters (PFIR) are investigated. The results of the study allow to establish the following:
the presence of noise in the channel of the digital quadrature heterodyne with a level from zero to half the
amplitude of the useful signal can increase the decimation factor of the corrective FIR filter one and a half
times. It has been experimentally established that the reduction of the decimation factor of the corrective FIR
filter can increase the noise level in the quadrature generator channel, while the amplitude of the useful
component at the DDC output decreases and distortion increases.
Ключові слова
частотна маніпуляція, інтерполяція, децимація, фільтрація сигналів, телекомунікаційна система, frequency manipulation, interpolation, decimation, signal filtering, telecommunication system
Бібліографічний опис
Бойко Ю. М. Особливості квазікогерентної обробки сигналів у засобах телекомунікацій з частотною маніпуляцією / Ю. М. Бойко, І. С. Пятін // Телекомунікаційні та інформаційні технології : наук. журн. / Держ. ун-т телекомунікацій. – Київ, 2018. – № 1 (58). – С. 27-39.
