Формоутворення неповних сферичних поверхонь на універсальних верстатах токарної групи
Вантажиться...
Дата
2017
Автори
Косіюк, М.М.
Костюк, С.А.
Kosiyuk, M.M.
Kostyuk, S.A.
Назва журналу
Номер ISSN
Назва тому
Видавець
Хмельницький національний університет
Анотація
В статті розглянуто область застосування та приведені характерні представники деталей машин з
неповними сферичними поверхнями. Проведено аналіз останніх досліджень і публікацій. Розглянуто методи
отримання штучних заготовок з конструктивним елементом у вигляді неповної сферичної поверхні. Розглянуто
питання формоутворення різанням неповних сферичних поверхонь деталей машин. Проведено аналіз існуючих
кінематичних схем лезової та абразивної обробки неповних сферичних поверхонь. Розглянуто конструкції
верстатних пристроїв для обточування неповних сферичних поверхонь. Запропоновано кінематичну схему процесу
обточування неповних сферичних поверхонь зі зміщеним інструментом на основі якої розроблено верстатний
пристрій. Отримані математичні залежності для визначення кутової подачі в залежності від режимів обробки.
In the article examined field of application and presented typical representatives of machine parts with incompletes spherical surfaces. Conducted analysis of recent research and publications. Considered Methods of obtaining billets from artificial constructive element in the form of incomplete spherical surfaces. Considered the question of forming incompletes spherical surfaces cutting machine parts. Conducted analysis of existing kinematics schemes edge cutting and abrasive processing incomplete spherical surfaces. Considered machine tool design devices for turning incompletes spherical surfaces. The proposed kinematic scheme machining processing incomplete spherical surfaces with a displacement tool based on which the device is designed for machining.
In the article examined field of application and presented typical representatives of machine parts with incompletes spherical surfaces. Conducted analysis of recent research and publications. Considered Methods of obtaining billets from artificial constructive element in the form of incomplete spherical surfaces. Considered the question of forming incompletes spherical surfaces cutting machine parts. Conducted analysis of existing kinematics schemes edge cutting and abrasive processing incomplete spherical surfaces. Considered machine tool design devices for turning incompletes spherical surfaces. The proposed kinematic scheme machining processing incomplete spherical surfaces with a displacement tool based on which the device is designed for machining.
Опис
Ключові слова
сферична поверхня, різання, метод, деталь, параметр, spherical surface, cutting, method, parts, parameter
Бібліографічний опис
Косіюк, М.М. Формоутворення неповних сферичних поверхонь на універсальних верстатах токарної групи [Текст] / М. М. Косіюк, С. А. Костюк // Вісник Хмельницького національного університету. Технічні науки. – 2017. – № 3. – С. 47-52.
