Використання точок розпрямлення 5-го порядку для синтезу важільних двокривошипних механізмів із зупинкою вихідної ланки
Вантажиться...
Дата
2016
Автори
Харжевський, В.О.
Kharzhevskyi, V.O.
Назва журналу
Номер ISSN
Назва тому
Видавець
Хмельницький національний університет
Анотація
В роботі розглядається питання синтезу важільних двокривошипних прямолінійно-напрямних
механізмів та побудованих на їх основі механізмів із зупинкою вихідної ланки методами кінематичної геометрії,
зокрема з використанням особливих точок шатунної площини – точок розпрямлення 5-го порядку. Як показано,
використання таких механізмів має ряд переваг, зокрема встановлено, що використання точок розпрямлення 5-
го порядку для синтезу двокривошипних механізмів дозволяє отримати механізми з тривалішими ділянками
наближення порівняно з використанням інших методів синтезу.
Abstract – The article is dedicated to the synthesis of the straight-line linkage mechanisms on the basis on four-bar linkage. These mechanisms are widely used in different branches of machinery where straight line path generating is required. Besides, those mechanisms can be used as basic mechanisms for the designing of dwell linkages. It is known that linkage mechanisms have a number of advantages in comparison with the other types of mechanisms, for example cam mechanisms. One of the type of the four-bar linkage is double-crank linkage. As shown in the article, methods of the kinematic differential geometry can also be used to design straight-line linkages on their basis. The synthesis of mentioned mechanisms was done by using of the special points on the coupler plane – 5th order straightening points. As shown, the usage of such mechanisms has a number of advantages: in particular it allows synthesizing of the mechanisms with larger dwells of an output link.
Abstract – The article is dedicated to the synthesis of the straight-line linkage mechanisms on the basis on four-bar linkage. These mechanisms are widely used in different branches of machinery where straight line path generating is required. Besides, those mechanisms can be used as basic mechanisms for the designing of dwell linkages. It is known that linkage mechanisms have a number of advantages in comparison with the other types of mechanisms, for example cam mechanisms. One of the type of the four-bar linkage is double-crank linkage. As shown in the article, methods of the kinematic differential geometry can also be used to design straight-line linkages on their basis. The synthesis of mentioned mechanisms was done by using of the special points on the coupler plane – 5th order straightening points. As shown, the usage of such mechanisms has a number of advantages: in particular it allows synthesizing of the mechanisms with larger dwells of an output link.
Опис
Ключові слова
прямолінійно-напрямні механізми, синтез, двокривошипні механізми, кінематична геометрія, точки розпрямлення 5-го порядку, straight-line mechanisms, synthesis, double-crank mechanisms, kinematic differential geometry, 5th order straightening points
Бібліографічний опис
Харжевський, В.О. Використання точок розпрямлення 5-го порядку для синтезу важільних двокривошипних механізмів із зупинкою вихідної ланки [Текст] / В. О. Харжевський // Вісник Хмельницького національного університету. Технічні науки. – 2016. – №1. – С. 103-108.
