Розрахунково-експериментальні методи оцінювання міцності металоскляних виробів реа
Вантажиться...
Файли
Дата
2020
Автори
Горошко, А.В.
Ковтун, І.І.
Крушинський, Д.О.
Goroshko, A.
Kovtun, I.
Krushynskyi, D.
Назва журналу
Номер ISSN
Назва тому
Видавець
Хмельницький національний університет
Анотація
У статті представлені результати досліджень міцності склоспаїв у виробах електронної техніки. Проведено
розрахунок допустиму розкиду фізико-механічних характеристик матеріалів вузла склоспаю, що забезпечують виконання
умови міцності склоспая, і запропоновано здійснюючи вхідний контроль фізико-механічних характеристик використаних
матеріалів з подальшим погодженням їх партій. Запропонована методика проектного розрахунку на міцність вузлів
металоскляних фотодатчиків РЕА.
The experience of using metal-glass electronics products indicates their low reliability due to mechanical destruction. As a rule, failure is caused by the insufficient ability of incandescent glass to wet the metal to form a tight bond, as well as by the inconsistent thermal expansion of glass and metal, which can cause a decrease in strength and depressurization of the seal when the assembly is cooled. The paper presents the results of studies of the strength of glass-sealed in electronic products. It is shown that the theory of thick-walled Lamé cylinders can be used for the calculation. The calculation of the permissible scatter of the physical and mechanical characteristics of the materials of the glass-weld assembly, ensuring the fulfillment of the strength condition of the glass-weld, was carried out, and it was proposed to carry out the incoming control of the physical and mechanical characteristics of the materials used with the subsequent approval of their batches. A method of design calculation for the strength of units of metal-glass photosensors of electronic equipment is proposed. In, a new design and technological concept of sealing electronic modules in aluminum alloy housings using a multifunctional coating based on Ni and Si, obtained by pulsed laser surfacing. A formula for determining the mobility of surfacing of one layer, taking into account which find the total duration of laser surfacing and the formation of a multifunctional coating. In it is noted that indium and some of its alloys can be used as a solder capable of wetting glass, ceramics and metals and connecting them together. Indium has a low melting point and is very mild; softness allows it to plastically deform and absorb stress due to the mismatch of thermal expansion. Due to the very low pressure, indium vapor is used in glass-metal seals used in vacuum technology and cryogenic applications.
The experience of using metal-glass electronics products indicates their low reliability due to mechanical destruction. As a rule, failure is caused by the insufficient ability of incandescent glass to wet the metal to form a tight bond, as well as by the inconsistent thermal expansion of glass and metal, which can cause a decrease in strength and depressurization of the seal when the assembly is cooled. The paper presents the results of studies of the strength of glass-sealed in electronic products. It is shown that the theory of thick-walled Lamé cylinders can be used for the calculation. The calculation of the permissible scatter of the physical and mechanical characteristics of the materials of the glass-weld assembly, ensuring the fulfillment of the strength condition of the glass-weld, was carried out, and it was proposed to carry out the incoming control of the physical and mechanical characteristics of the materials used with the subsequent approval of their batches. A method of design calculation for the strength of units of metal-glass photosensors of electronic equipment is proposed. In, a new design and technological concept of sealing electronic modules in aluminum alloy housings using a multifunctional coating based on Ni and Si, obtained by pulsed laser surfacing. A formula for determining the mobility of surfacing of one layer, taking into account which find the total duration of laser surfacing and the formation of a multifunctional coating. In it is noted that indium and some of its alloys can be used as a solder capable of wetting glass, ceramics and metals and connecting them together. Indium has a low melting point and is very mild; softness allows it to plastically deform and absorb stress due to the mismatch of thermal expansion. Due to the very low pressure, indium vapor is used in glass-metal seals used in vacuum technology and cryogenic applications.
Опис
Ключові слова
склоспай, фотодатчик, міцність, електронні вироби, Glass-to-metal seal, Photosensor, Strength, Electronic Products
Бібліографічний опис
Горошко А. В. Розрахунково-експериментальні методи оцінювання міцності металоскляних виробів РЕА / А. В. Горошко, І. І. Ковтун, Д. О. Крушинський // Вимірювальна та обчислювальна техніка в технологічних процесах. – 2020. – № 2. – С. 17-21.
