Оцінювання якісних показників пристроїв синхронізації сигналів засобів телекомунікацій
Вантажиться...
Дата
2015
Автори
Бойко, Ю.М.
Ночка, Р.Ю.
Boiko, J.M.
Nochka, R.Yu.
Назва журналу
Номер ISSN
Назва тому
Видавець
Хмельницький національний університет
Анотація
Проведено аналіз принципів отримання максимальної правдоподібної оцінки затримки в пристроях
синхронізації сигналів засобів телекомунікацій. Сформовано Simulink‐модель пристрою синхронізації та методом
імітаційного моделювання отримано бітові послідовності для аналізу його роботи. Здійснено аналіз та
формалізацію опису пристроїв синхронізації таких, які керуються рішенням і таких, які не керуються рішенням.
Розглянуто метод оцінювання часового зсуву без зворотного зв’язку за рішенням, шляхом використання
симетричних властивостей сигналу на виході узгодженого фільтра або корелятора з вікнами на затримку‐
випередження. Наведено залежності для дисперсії максимальної правдоподібної оцінки пристрою синхронізації від
відношення сигнал/шум. Отримано аналітичні вирази та залежності відхилення помилки синхронізації від
відношення сигнал/шум на виході фазового детектору. Сформовано діаграми станів для оцінювання роботи
цифрового пристрою синхронізації за наявності випадку, який характеризується станом помилки та діаграму
помилки для аналізу часу до зриву синхронізації. Проведено визначення результатів розрахунку середнього часу до
зриву синхронізації від відношення сигнал/шум.
Abstract ‐ The analysis principles to maximize credible evaluation delay devices synchronization of telecommunications signals. Formed Simulink‐device synchronization model by simulation and received bit sequence analysis of his work. The analysis and formalization description of synchronization devices are guided by such decisions and which are not governed by the decision. The method of evaluation of temporal change without feedback for decision by using symmetric properties of the signal at the output of the matched filter or correlator with windows on delay‐ahead. Powered depending dispersion maximum credible evaluation device synchronization of the signal/noise ratio. Analytical expressions and dependence deviation error of synchronization signal/noise ratio at the output of the phase detector. Formed state diagram for the evaluation of digital device synchronization condition characterized by the presence of errors as errors and chart analysis of time to failure of synchronization. A determination of the results of the calculation of the average time to failure of synchronization of the signal/noise ratio.
Abstract ‐ The analysis principles to maximize credible evaluation delay devices synchronization of telecommunications signals. Formed Simulink‐device synchronization model by simulation and received bit sequence analysis of his work. The analysis and formalization description of synchronization devices are guided by such decisions and which are not governed by the decision. The method of evaluation of temporal change without feedback for decision by using symmetric properties of the signal at the output of the matched filter or correlator with windows on delay‐ahead. Powered depending dispersion maximum credible evaluation device synchronization of the signal/noise ratio. Analytical expressions and dependence deviation error of synchronization signal/noise ratio at the output of the phase detector. Formed state diagram for the evaluation of digital device synchronization condition characterized by the presence of errors as errors and chart analysis of time to failure of synchronization. A determination of the results of the calculation of the average time to failure of synchronization of the signal/noise ratio.
Опис
Ключові слова
цифрова синхронізація, керований генератор, дисперсія оцінювання, зрив синхронізації, digital synchronization, controlled oscillator, variance estimation, synchronization failure
Бібліографічний опис
Бойко, Ю.М. Оцінювання якісних показників пристроїв синхронізації сигналів засобів телекомунікацій [Текст] / Ю. М. Бойко, Р. Ю. Ночка // Вісник Хмельницького національного університету. Технічні науки. – 2015. – № 1. – С. 144-155.
