Аналіз спектральних складових сумарного сигналу для багатошкального фазового методу аналізу стану лінії зв'язку. Повідомлення 2
Вантажиться...
Дата
2013
Автори
Горященко, К.Л.
Horiashchenko, K.L.
Назва журналу
Номер ISSN
Назва тому
Видавець
Хмельницький національний університет
Анотація
Розглянуто особливості застосування фазового методу визначення пошкоджень в провідниковій лінії при
застосуванні обмежень, що накладаються властивостями об’єкту дослідження – провідниковою лінією.
Визначено, що отриманий сумарний сигнал буде складатись з сигналів відбиттів, які мають різну частоту
обертання вектору кута відбиття. Встановлено, що при застосуванні методів цифрового спектрального аналізу
потрібно визначення складових сигналу при апріорі невідомих значеннях початкового зсуву фази, а також при
апріорі нецілій кількості періодів, що попадають у вікно аналізу
In article feature usage of the phase method with multiplies frequencies for determining damage in wiring line when applying constraints imposed properties of the object of study conductor line. Found that lower frequency boundary is due to the stabilization parameter of line, upper boundary – by upper allowed frequency for signal passing. Determined that the total received signal will consist of signal reflections that have different rotational speed of reflection angle. The analysing signal must always be within the allowable frequency. This leads to the fact that the reflection signals get additional value of phase shift as initial angle. It is established that the usage of different methods of digital spectral analysis require to determine the signal components with unknown values of the initial phase shift , as well as with noninteger number of periods that fall within the window of analysis
In article feature usage of the phase method with multiplies frequencies for determining damage in wiring line when applying constraints imposed properties of the object of study conductor line. Found that lower frequency boundary is due to the stabilization parameter of line, upper boundary – by upper allowed frequency for signal passing. Determined that the total received signal will consist of signal reflections that have different rotational speed of reflection angle. The analysing signal must always be within the allowable frequency. This leads to the fact that the reflection signals get additional value of phase shift as initial angle. It is established that the usage of different methods of digital spectral analysis require to determine the signal components with unknown values of the initial phase shift , as well as with noninteger number of periods that fall within the window of analysis
Опис
Ключові слова
вікно аналізу, початковий кут зсуву фази, зсув фази, window analysis, the initial angle of phase shift, phase shift
Бібліографічний опис
Горященко, К.Л. Аналіз спектральних складових сумарного сигналу для багатошкального фазового методу аналізу стану лінії зв'язку. Повідомлення 2 [Текст] / К. Л. Горященко // Вимірювальна та обчислювальна техніка в технологічних процесах. – 2013. – №4. – С. 58-62.
