Use of SolidWorks for determination of working device for installation and disassembly of brake drums
Вантажиться...
Дата
2022
Автори
Rudyk, Oleksandr Yuhymovych
Ziabkin, Artem Olegovych
Назва журналу
Номер ISSN
Назва тому
Видавець
MDPC Publishing. Berlin, Germany
Анотація
After a long stay on the axle shaft, the brake drum is difficult to remove due to the presence of its oxidation products (in the axle-drum connection, instead of landing with a gap, an interference is obtained). Therefore, a device for mounting and dismounting the brake drums of trucks has been proposed. The proposed device refers to garage equipment. The purpose of its creation is to increase the reliability of holding brake drums, to accelerate and ensure the safety of assembly and dismantling. The purpose of the work - with the help of SolidWorks to determine the efficiency of the crossbar of the device for mounting and dismounting brake drums.
Опис
The CAE / CAD automated SolidWorks complex was used for the study. The application of this program (SolidWorks Simulation) uses a geometric model of the part to form a computational model. For the designed device for installation and dismantling of brake drums the maximum effort on a crossbeam which will not lead to safety violations (at the minimum admissible safety margin [n] = 2,5) will make 5200 N.
Ключові слова
Бібліографічний опис
Rudyk O. Yu. Use of SolidWorks for determination of working device for installation and disassembly of brake drums / O Yu. Rudyk, F. O. Ziabkin // Modern scientific research: achievements, innovations and development prospects. Proceedings of the 8th International scientific and practical conference. MDPC Publishing. Berlin, Germany, 2022. – Pp. 21-27.
