Експериментальні дослідження автономного приводу для пресового обладнання машин легкої промисловості на базі гідроштовхачів
Вантажиться...
Файли
Дата
2018
Автори
Неймак, В.С.
Лісевич, С.П.
Смутко, С.В.
Прибега, Д.В.
Neymak, V.S.
Lisevich, S.P.
Smutko, S.V.
Pribega, D.V.
Назва журналу
Номер ISSN
Назва тому
Видавець
Хмельницький національний університет
Анотація
Штовхачі представляють собою сукупність двигуна і поступальної передачі, тобто автономного,
частіше всього конструктивно компактного, приводу з поступальним рухом робочого органу. Комбінація
гідронасоса з поршнем дозволяє вибрати в якості приводу електродвигун з відносно невеликою потужністю та
моментом і при цьому отримати значно збільшену направлену силу. Перспективним є застосування
гідроштовхачів в якості приводу для пресового гладильного обладнання. Дана стаття присвячена
експериментальним дослідженням автономного приводу на базі гідроштовхачів. Метою досліджень є
встановлення відповідності їх силових характеристик вимогам, що висуваються до пресового обладнання легкої
промисловості. В основу експериментальних досліджень покладено дослідження часу підйому та опускання штока
гідроштовхача під різними навантаженнями, а саме 150, 200, 250 Н. На основі проведеного циклу
експериментальних досліджень встановлено, що гідроштовхач має динамічні характеристики, які дозволяють
застосовувати його у якості приводу пресового обладнання легкої промисловості для виконання операцій, що не
потребують великих технологічних зусиль, таких як вставка блочків, люверсів, пробивання отворів.
Pushers represent a combination of engine and translational transmission, that is, an autonomous, often constructively compact, drive with a translatory motion of the working body. The combination of the hydraulic pump and the piston allows you to select as an actuator an electric motor with a relatively small power and moment, and at the same time obtaining a significantly increased directional force. The prospect of the use of hydraulic pushers as a drive for press ironing equipment looks like. Modern hydraulic pushers can provide both pressure and pressure requirements, while having a number of significant advantages over other mechanisms of reciprocating motion. When installing a hydraulic jack on an ordinary hydraulic ironing press, there is no need to install a water boat and pipelines. The preliminary assessment showed the promise of the proposed direction, but for the final answer it was necessary to conduct a series of experimental analytical studies of press ironing equipment with a stand-alone drive on the basis of hydraulic pushers. This article is devoted to experimental research of autonomous drive on the basis of hydraulic pushers in order to establish the conformity of their power characteristics to the requirements put forward for press equipment of light industry. The basis of experimental research is the study of the time of lifting and lowering the rod of a hydraulic shaft under different loads, namely 15, 20, 25 KGs. On the basis of the conducted cycle of experimental studies, it has been established that the hydraulic shock absorber has good dynamic characteristics and can be used as a drive for light industry equipment for operations that do not require major technological efforts, such as insertion of blocks, eyelets, punching holes.
Pushers represent a combination of engine and translational transmission, that is, an autonomous, often constructively compact, drive with a translatory motion of the working body. The combination of the hydraulic pump and the piston allows you to select as an actuator an electric motor with a relatively small power and moment, and at the same time obtaining a significantly increased directional force. The prospect of the use of hydraulic pushers as a drive for press ironing equipment looks like. Modern hydraulic pushers can provide both pressure and pressure requirements, while having a number of significant advantages over other mechanisms of reciprocating motion. When installing a hydraulic jack on an ordinary hydraulic ironing press, there is no need to install a water boat and pipelines. The preliminary assessment showed the promise of the proposed direction, but for the final answer it was necessary to conduct a series of experimental analytical studies of press ironing equipment with a stand-alone drive on the basis of hydraulic pushers. This article is devoted to experimental research of autonomous drive on the basis of hydraulic pushers in order to establish the conformity of their power characteristics to the requirements put forward for press equipment of light industry. The basis of experimental research is the study of the time of lifting and lowering the rod of a hydraulic shaft under different loads, namely 15, 20, 25 KGs. On the basis of the conducted cycle of experimental studies, it has been established that the hydraulic shock absorber has good dynamic characteristics and can be used as a drive for light industry equipment for operations that do not require major technological efforts, such as insertion of blocks, eyelets, punching holes.
Опис
Ключові слова
гідроштовхач, пресове обладнання легкої промисловості, пресове гладильне обладнання, hydraulic press, press equipment for light industry, press ironing equipment
Бібліографічний опис
Експериментальні дослідження автономного приводу для пресового обладнання машин легкої промисловості на базі гідроштовхачів [Текст] / В. С. Неймак, С. П. Лісевич, С. В. Смутко, Д. В. Прибега // Вісник Хмельницького національного університету. Технічні науки. – 2018. – № 5. – С. 191-193.
